Power x 3 with the new 750 Weight Display

The new Detecto 750 weighing indicator is the perfect weight display for all applications. The recharging circuitry is “Built-In” to the 750 display. Utilizing the AC adapter and installing Ni-Cad “AA” batteries, you can have a truly free-standing scale in any office environment.

• Operate up to 250 hours on new alkaline batteries.
• Operate up to 100 hours on NiCad batteries before recharging. (Recharging time is approximately 8 hours and the scale can be operated during this time.)

• Low-profile scale base with 7.25 ft / 2.2 m cable to a remote display
• Large, easy-to-read 1 in / 25 mm high LCD digits
• Body Mass Index (BMI) calculation to determine health status
• The display may be wall-mounted or set on the countertop (bracket included)
• 14.2 in W x 15.8 in D x 2.4 in H / 36.0 cm W x 40.2 cm D x 6.1 cm H platform size
• 550 lb x 0.2 lb / 250 kg x 0.1 kg capacity
• Portable and lightweight for easily changing weighing locations based on patient needs
• Mother/Baby mode factors the weight of infants and toddlers held by an adult
• Weight, Height, and Body Mass Index
• Manual input height entry from 2 ft 0.0 in – 7 ft 10.5 in by 0.5 in (60.0 cm – 240.0 cm by 1cm)
• Audible beep confirmation (short beep when a key is pressed, and a long beep for when weight is stable and locked)
• Selectable Auto Shut-Off feature to conserve batteries (up to 9 minutes)
• Auto Weight Lock feature on stable weight
• 6 AA batteries included. SOLO-RI-AC model comes with an AC adapter
• Included carpet feet improve weighing accuracy on carpeting
• 8 simple buttons that are easily identifiable in any language for use around the world
• USB port allows you to output measurement data to EMR/EHR software by pressing the Print key
• The hold/Release key lets you hold a patient weight onscreen until you can record it in their recordkeeping
• Comes ready for weighing right out of the box with included batteries, manual, wall-mount and desktop bracket, mounting screws, and carpet feet
• OneWeigh units locking into Pounds or Kilograms avoids dosage errors based on incorrect units
• Optional carrying case with internal Velcro straps available (model PRODOC-CASE)
• The 7.25 ft/2.2 m cable from the scale base to the indicator allows you to set the display wherever it’s most convenient
• 14 x 15-inch platform with ribbed rubber mat is only 2.4 inches high making it easy for patients to step on/off
• DETECTO’s SOLO-RI is also available with an eye-level column as model SOLO

475 Mechanical Medical Cha

Features

WinDDE Server communicates with up to 20 weight indicators attached to a computer. Weight indicators may be connected using standard computer serial ports or via ethernet using TCP/IP. The weight and status of the weight indicators are made available to spreadsheets, databases, and industrial control applications by means of Dynamic Data Exchange, or NetDDE for networked computers. Weight and time stamp information may be automatically captured to Excel® creating a new row of information for each stable weight above the threshold. Alternatively, the capture feature may be based on the indicator print button to capture a row of data each time the print key is pressed on the indicator.

Weight Monitoring Industrial Control Software such as Rockwell RSView®, Automation Direct®, Lookout Direct®, and spreadsheet programs, such as Microsoft Excel® may be used. A spreadsheet cell, such as A1, shows continuously updating weight. The spreadsheet may show a continuously updating bar graph. Formulas in the spreadsheet may show a flashing indication if the weight exceeds or drops below certain levels. The WinDDE command for the spreadsheet to read weight is simply =windde|scale!wt Automatic Stable Weight Capture to Excel® After a weight is placed on the scale and the indicator sees a stable weight, the weight is placed in a spreadsheet cell, such as A5. The operator removes the weight, and the procedure is repeated, but the weight value is placed in the next spreadsheet row, such as A6. Printer Port Capture to Excel® After a weight is placed on the scale, the operator at the indicator may press the Print key on the indicator. Instead of printing, the printout information from the indicator is sent to the computer. The computer sets the spreadsheet cells, such as E3 Gross Weight, F3 Tare Weight, G3 Net Weight, etc. The operator then may remove the weight, and the procedure is repeated, but the information is placed in the next spreadsheet row, such as E4, F4, G4, etc. Computer Data Collection After a weight is placed on the scale, the operator may type information at the computer, such as an ID number to associate the weight. The computer stores the information in a database or spreadsheet. The operator then may remove the weight. With certain weight indicators, such as the Cardinal model 220, weight monitoring, automatic stable weight capture to Excel® and printer port capture to Excel® can be used simultaneously. Windows® 2000 or XP must be used if more than ten indicators will be connected.

Microsoft Excel®, Microsoft Access®, Wonderware InTouch®, Automation Direct®, Lookout Direct®, and Rockwell Automation RSView® are just a few of the well-known applications which can be used with WinDDE.
